Used in natural gas and petroleum distribution systems, KPS’s API Line Pipe are longitudinal electric welded steel pipe available in PSL1 and PSL2 specification made in accordance with ANSI/API specification 5L under license: API-0391 and API-1104.

KPS API line pipes are marked and embossed (inside or outside) according to customer requirements. The nominal diameter of KPS line pipes ranges from ¾” to 12 ¾” with the length ranging from 6 meters to 12.20 meters.

Tube Mill Section:

KPS’s state-of-the-art U.S. and Japanese tub

e mills are used for the manufacturing of API line pipe and are equipped with:

• Solid state/high frequency welder (from Thermatool, UK)
  • For high integrity forge welding
• Seam annealing
  • The weld seam and entire heat affected zone is heat treated and processed to ensure no un-tempered Martensite remains on the heat affected zone.
• Inner Bead Trimming (Diameter 4″ and 6″)
  • Carried out to meet API Specification 5L



Product Testing Features:

• NDT unit (Eddy Current Flaw Detector)
  • Eddy Current testing is used to detect surface and internal flaws or imperfections like seam, slivers, open weld and incomplete welds
• Hydrostatic Tests
  • Each length of KPS API Line Pipe is manufactured to withstand leakage at hydrostatic test pressure are specified in the standard. In order to ensure that every length of pipe is tested, the hydro testers at KPS are equipped with a test pressure gauge and timer. We ensure that no pipe is dispatched until hydro testing has been performed. Size and grade wise hydrostatic test pressures are given in table overleaf
